76020 Series Thrust Angular Contact Ball Bearings for Screw Drives

76020 Ball screw support bearings

Ball screw support bearings can meet the application for high precision, high load capacity, high rigidity, low friction, easy installation, maintenance-free or low maintenance screw drive . These applications require safe radial and axial support and extremely precise axial guidance of thespindle.Ball screw support bearings have contact angle of 60°, which can withstand high axial and radial forces. Commonarrangment include DB, DF, DT, etc. This series also have design with two seals, which is convenient for customers to install and use. The main principles for selecting screw drive bearings are axial rigidity, load capacity, running accuracy, speed and friction torque. Other factors that need to be considered are the moment rigidity of the bearing and the ability to adapt to the deflection between the shaft and the bearing seat. Installation and seals also need to be considered.

Product Details

Designation	Dimensions(mm)			Basic loading		Limiting Speed		Weight
	Dimensions(mm)			Basic loading		Limiting Speed		Weight
	d	D	B	Ca	Coa	Greas	Oil	≈
	mm			KN		r/min		Kg
7602012TVP	20	32	10	11.6	12.5	17000	24000	0.04
7602015TVP	15	35	11	12.5	15	15000	20000	0.05
7602017TVP	17	40	12	16.6	20	13000	18000	0.07
7602020TVP	20	47	14	19.3	25	12000	17000	0.13
7602025TVP	25	52	15	22	30.5	11000	16000	0.16
7602030TVP	30	62	16	26	39	9000	13000	0.24
7602035TVP	35	72	17	30	50	8000	11000	0.34
7602040TVP	40	80	18	37.5	64	7000	9500	0.44
7602045TVP	45	85	19	38	68	6700	9000	0.5
7602050TVP	50	90	20	39	75	6300	8500	0.67
7602055TVP	55	100	21	40.5	81.5	6000	8000	0.75
7602060TVP	60	110	22	56	112	5000	6700	0.96
7602065TVP	65	120	23	57	122	4800	6000	1.32
7602070TVP	70	125	24	65.5	137	4500	6000	1.45
7602075TVP	75	130	25	67	150	4300	5600	1.45
7602080TVP	80	140	26	76.5	175	4000	5300	1.76
7602085TVP	85	150	28	86.5	196	3800	5000	2.19
7602090TVP	90	160	30	98	224	3600	4800	2.69
7602095TVP	95	170	32	122	285	3200	4300	3.91
7602100TVP	100	180	34	146	355	2800	3800	5.5
7602120TVP	120	215	40	176	425	2600	3600	6.5
7602130TVP	130	230	40	180	455	2400	3400	7.4

Thrust angular contact ball bearings for screw drives can handle heavy axial loads and occasional overloads better than conventional bearing designs. Thrust angular contact ball bearings for screw drives can only handle axial loads in one direction and are therefore matched with a second set of bearings, or mounted in sets. These bearings are standardized for universal matching and can be mounted in sets of up to four bearings to achieve different bearing configurations and the performance level of a matched bearing set. The unique heat treatment method helps the bearings maintain a constant preload throughout their operating life.
Universally matchable single-way bearings can be configured in different configurations depending on the stiffness and load requirements of the application. If misalignment between bearing positions cannot be avoided, a face-to-face bearing arrangement is recommended. It is less sensitive to misalignment than a back-to-back bearing arrangement. A combination of tandem and face-to-face or back-to-back arrangements is often used to maximize the stiffness or load carrying capacity of a bearing set in one direction. For example, when it is necessary to support an extended, preloaded vertical or cantilevered ball screw drive will appear.
Our company has professional sales and technical engineers who are responsible for providing users with technical consultation, technical services and product technical training on precision bearing data and installation and use. Perfect pre-sales, in-sales and after-sales services constitute a guarantee system for high-quality services, providing users with reliable quality bearing products and creating excellent user experience and rich benefits for every customer.

If you have any questions about products and services, please contact the company's service department directly.
