Spring bushing bearings

Spring bushing bearings are mainly used in continuous casting machines. Spring bushing bearings mainly include inner and outer rings of a helical spring structure, rolling elements, cages, end covers, and outer shells of the outer rings. The two ends of the shells fit the end covers, and there is a gap between the shells and the outer rings. A journal is provided on the inner side of the inner ring, and a circular left sealing plate and a right sealing plate are provided on the journals. During processing, the bearings undergo rolling, annealing, quenching, high-temperature tempering, shaping, cutting off the spiral tails of the inner and outer rings, and outer diameter grinding. Since the inner and outer rings are helical spring bodies, temperature changes allow the inner and outer rings to freely expand and contract in the axial and radial directions, so they will not get stuck during work. The gaps in the inner and outer rings of the helical spring bodies can store grease and foreign matter, which is conducive to lubrication and removal of foreign matter, and is beneficial to increasing the life of the bearing. The helical spring body makes the bearing elastic, they can withstand impact resistance, and maintain normal operation under flexural deformation.

Product Details

Model	Dimension	Weight	Static Load [kN]	Dynamic Load [kN]
10456e	45/80 mm x 80/70 mm	2,1	327	205
11588e	50/80 mm x 75/70 mm	1,6	332	189
10455e	50/85 mm x 80/70 mm	2,2	375	220
8227e	50/95 mm x 85/50 mm	2	320	205
7565e	50/95 mm x 85/50 mm	3	320	205
11166e	55/85 mm x 75/70 mm	1,8	380	215
11167e	60/95 mm x 75/70 mm	2,4	432	230
10203e	60/89 mm x 73/63 mm	1,6	400	195
8545e	65/105 mm x 90/64 mm	2,2	390	245
11590e	65/95 mm x 75/70 mm	2	410	208
11259e	75/105 mm 75/70 mm	2,7	520	255
10227e	75/104 mm x 73/63 mm	1,9	440	203
10236e	80/120 mm x 73/63 mm	3	530	265
8546e	85/125 mm x 90/64 mm	2,7	530	295
10389e	90/121 mm x 73/63 mm	2,4	528	247
8132e	35/60 mm x 64/38 mm	0,6	115	82
2671e	35/62 mm x 50/36 mm	0,6	90	65
2436e	35/65 mm x 56,5/38 mm	0,65	95	50
2955e	35/65 mm x 64/38 mm	0,7	100	85
11386e	40/68 mm x 58/45 mm	0,9	160	101
10144e	40/71 mm x 60/45 mm	0,9	145	110
10772e	45/67 mm x 50/40 mm	0,6	130	80
10063e	45/67 mm x 73/63 mm	0,8	240	130
10145e	45/75 mm x 86/70 mm	1,3	260	175
10541e	50/80 mm x 75/70 mm	1,5	350	215
11941e	50/85 mm x 57/45 mm	1,4	153	108
8679e	50/85 mm x 73/45 mm	1,5	183	140
3110e	50/95 mm x 95/70 mm	2,1	285	215
11181e	55/80 mm x 73/63 mm	1,2	275	140
6204e	55/90 mm x 73/63 mm	2	320	185
8466e	60/89 mm x 73/63 mm	1,6	365	175
8065e	60/89 mm x 73/63 mm	1,6	345	160
6205e	60/95 mm x 73/63 mm	2	365	200
5522e	60/110 mm x 105/94 mm	3,4	515	340
9138e	62/89 mm x 73/63 mm	1,5	350	190
8511e	70/99 mm x 73/63 mm	1,7	390	180
2675e	70/120 mm x 71,5/50 mm	3	315	205
11189e	75/104 mm x 73/63 mm	1,8	393	188
11397e	75/105 mm x 73/63 mm	3	431	200
11190e	90/121 mm x 73/63 mm	2,4	538	250
558e	30/65 mm x 80/40 mm	0,70	41,00
351e	30/65 mm x 40 mm	0,55	41,00
499e	40/75 mm x 120/58 mm	1,08	72,00
375e	40/75 mm x 58 mm	0,97	72,00
033e	40/82 mm x 69 mm	1,50	95,00
035e	40/82 mm x 140/69 mm	1,70	95,00
5872e	45/95 mm x 70 mm	2,10	115,00
11112e	50/92 mm x 106/69 mm	1,84	110,00
10531e	50/92 mm x 69 mm	1,75	110,00
1171e	55/97 mm x 69 mm	1,85	117,00
1170e	55/97 mm x 140/69 mm	1,96	117,00
042e	65/102 mm x 140/69 mm	2,16	145,00
4854e	65/102 mm x 69 mm	1,96	145,00
2464e	70/120 mm x 140/60 mm	3,14	125,00
7864e	70/107 mm x 69 mm	1,97	165,00
8125e	80/140 mm x 50 mm	3,00	130,00
8126e	80/140 mm x 55/50 mm	3,10	130,00
2751e	110/170 mm x 100/70 mm	5,39	218,00

The inner and outer rings of the spiral spring bearing are rolled with spring steel, which makes the device elastic and has a gap between the inner and outer rings. Therefore, the clearance can be automatically compensated in a high temperature environment, and the self-improvement and cleaning capabilities of the lubrication conditions can be resisted. Moreover, the working condition can be maintained under flexural deformation, which is very suitable for the application conditions of continuous casting rolling mills and high-temperature transmission equipment in steel plants.

Features of spiral spring bearings:

1. Automatic compensation of clearance in a high temperature environment: Since the inner and outer rings of this bearing are in the shape of a spiral spring, the inner and outer diameters can be freely expanded and contracted in the axial and radial directions under temperature changes, so the clearance can be basically unchanged in a high temperature environment, and it will not cause jamming.

2. Impact resistance: Since the inner and outer rings of this bearing are spiral spring bodies, they have strong hardness and stability after high-temperature quenching, tempering, and shaping.

3. Self-improvement and cleaning of lubrication conditions: Since the inner and outer rings and spiral rollers of this bearing have spiral grooves for storing grease and dirt, it is conducive to lubrication and removal of impurities, so it can achieve self-improvement and cleaning of lubrication conditions, and can extend the operating life of the bearing.

4. Can maintain working condition under flexural deformation. Since the inner and outer rings of this type of bearing are spring-wound, the bearing is elastic and has a gap between the inner and outer rings, so it can maintain working condition under flexural deformation and other conditions.

Our company has professional sales and technical engineers who are responsible for providing users with technical consultation, technical services and product technical training on precision bearing data and installation and use. Perfect pre-sales, in-sales and after-sales services constitute a guarantee system for high-quality services, providing users with reliable quality bearing products, and creating a good user experience and rich benefits for every customer.

If you have any questions about products and services, please contact the company's service department directly.
